Product Specification
Clik for customSize
Click to change mm to inch
| Art No. | Tube Ø mm | Max. Adjustment mm | B | C | D | FINISH | Wheel Ø mm | Remarks | |
|---|---|---|---|---|---|---|---|---|---|
| STIJW3063SP | 42 | 166 | 360 | 151 | 591 | Zinc Plated | 200 | -- | Enquiry |
| STIJW4224SP | 42 | 166 | 360 | 151 | 591 | Zinc Plated | 200 | Includes Bracket | Enquiry |
| STIJW4062SP | 48 | 166 | 350 | 151 | 576 | Zinc Plated | 200 | Includes Bracket | Enquiry |
| STIJW7628SP | 48 | 166 | 350 | 151 | 576 | Zinc Plated | 200 | -- | Enquiry |
| STIJW2343SP | 48 | 221 | 400 | 151 | 641 | Zinc Plated | 260 | -- | Enquiry |
| STIJW56844SP | 48 | 271 | 520 | 151 | 871 | Zinc Plated | 230 | -- | Enquiry |
| STIJW56849SP | 48 | 271 | 520 | 151 | 871 | Zinc Plated | 230 | Includes Bracket | Enquiry |
| STIJW21637SP | 60 | 283 | 565 | 93 | 771 | Galvanized | 200 | -- | Enquiry |
| STIJW14461SP | 70 | 305 | 460 | 375 | 986 | Red Oxide | 280 | -- | Enquiry |
