Product Specification
Clik for customSize
Click to change mm to inch
| CODE | ADJUSTMENT MIN | ADJUSTMENT MAX | 1 FORK | 2 LIFT ROD | 3 GEAR BOX | 4 KNUCKLE | WEIGHT KG | ASSY. LESS FORK P.NO. | WEIGHT KG | |
|---|---|---|---|---|---|---|---|---|---|---|
| ST-K 40929 | 495 | 565 | K40937 | 325 | K539 | K1795 | 4.67 | K16761 | 3.24 | Enquiry |
| ST-K 575 | 500 | 600 | K392 | K237 | K539 | K1795 | 4.79 | K16762 | 3.05 | Enquiry |
| ST-K 3233 | 475 | 575 | K2985 | K237 | K539 | K1795 | 4.78 | K16762 | 3.05 | Enquiry |
| ST-K 576 | 600 | 690 | K392 | K238 | K539 | K1795 | 5.00 | K16763 | 3.25 | Enquiry |
| ST-K 572 | 545 | 640 | K392 | K234 | K539 | K1795 | 4.84 | K16764 | 3.09 | Enquiry |
| ST-K 4290 | 520 | 630 | K4281 | K4285 | K4280 | K4282 | 6.15 | K16766 | 4.21 | Enquiry |
| ST-K 4292 | 565 | 675 | K4281 | K4288 | K4280 | K4282 | 6.30 | K16767 | 4.36 | Enquiry |
| ST-K 8626 | 665 | 770 | K8625 | K4288 | K4280 | K4282 | 9.80 | K16767 | 4.36 | Enquiry |
| ST-K 16863 | 575 | 660 | K8625 | K16865 | K4280 | K4282 | 9.89 | K16864 | 3.09 | Enquiry |
| ST-K 16874 | 510 | 605 | K2985 | K234 | K539 | K1795 | 4.97 | K16764 | 3.09 | Enquiry |
| ST-K 16875 | 565 | 655 | K2985 | K238 | K539 | K1795 | 4.99 | K16763 | 3.25 | Enquiry |
| ST-K 16876 | 650 | 760 | K16877 | K4288 | K4280 | K4282 | 10.02 | K16767 | 4.36 | Enquiry |
| ST-K 579/FD3000 | 560 | 660 | K392 | K243 | K539 | K1795 | 5.01 | K16765 | 3.26 | Enquiry |
| ST-K 11317/FD4000 | 725 | 825 | K11315 | K243 | K539 | K1795 | 6.85 | K16765 | 3.26 | Enquiry |
